Hongkong Meike Digital Technology Co., Ltd

MK5202B 6-24X52FFP

Fit:

Major function:
Support to:
Feature
CHENGDU MEIKE OPTICS CO., LTD
Riflescope Specifications
6-24X52FFP
Specification
Power 6X~24X Illuminated reticle Special Notes:
Objective (mm) 52 Illuminated color 1. Erector Tube must be secured with metal screws. Yes
Focal Plane first Battery 2. Erector Tube must have metal-to-metal contact. Yes
Tube Diameter(mm) 34 Parallax Focus:       YES 3. Low Temp Epoxy may be used with Erector Tube. Yes
Tube Material 6061-T6 Light Transmission Percentage (%) 89% 4. Fogproof with Dry Nitrogen Yes
Finish (Anodized?) Anodized Recoil: "g's" & # of times 1000G/100times 5. Recoil: 1000 Rounds Yes
Tube/Body Color(s) W/E Clicks 0.05MIL
     Black                                 [ √ ] Clicks per Turn 120
     Silver                                  Weight (oz/g)
Reticle Type                              Glass Etched Reticle Waterproof:       YES
Eye Relief Fogproof:          YES
         '@ LX (mm) 92 Shockproof:       YES
         '@HX (mm) 88 Elevation Adjustment Range (MOA) 70
FOV Windage Adjustment Range (MOA) 45
                   '@LX (ft.@100yds) 18.7 Parallax Setting  30m-infinity
                   '@HX (ft.@100yds) 4.6
FOV
                   '@LX (m.@100m) 6.2
                   '@HX (m.@100m) 1.54
Exit Pupil
       '@ LX (mm) 8.57
       '@HX (mm) 2.17
Lens Coating Material
  Fully Coated
  Multi Coated
  Fully Multi Coated             [ √ ] Sunshade:    Optional
Fast Focusing System:    YES Mounts: Optional
