| CHENGDU MEIKE OPTICS CO., LTD | |||||||||||||
| Riflescope Specifications |
|
|
|||||||||||
| 4-16X40SF | |||||||||||||
| Specification | |||||||||||||
| Power | 4X~16X | Illuminated reticle | Special Notes: | ||||||||||
| Objective (mm) | 40 | Illuminated color | 1. Erector Tube must be secured with metal screws. | Yes | |||||||||
| Focal Plane | second | Battery | 2. Erector Tube must have metal-to-metal contact. | Yes | |||||||||
| Tube Diameter(mm) | 30 | Parallax Focus: | YES | 3. Low Temp Epoxy may be used with Erector Tube. | Yes | ||||||||
| Tube Material | 6061-T6 | Light Transmission Percentage (%) | 89% | 4. Fogproof with Dry Nitrogen | Yes | ||||||||
| Finish (Anodized?) | Anodized | Recoil: "g's" & # of times | 1000G/100times | 5. Recoil: 1000 Rounds | Yes | ||||||||
| Tube/Body Color(s) | W/E Clicks | 0.1MIL |
|
||||||||||
| Black | [ √ ] | Clicks per Turn | 60 | ||||||||||
| Silver | Weight (oz/g) | 597g | |||||||||||
| Reticle Type | Metal Reticle | Waterproof: | YES | ||||||||||
| Eye Relief | Fogproof: | YES | |||||||||||
| '@ LX (mm) | 112 | Shockproof: | YES | ||||||||||
| '@HX (mm) | 90 | Elevation Adjustment Range (MOA) | 60 | ||||||||||
| FOV | Windage Adjustment Range (MOA) | 60 | |||||||||||
| '@LX (ft.@100yds) | 23 | Parallax Setting | 10yds-infinity | ||||||||||
| '@HX (ft.@100yds) | 5.8 | ||||||||||||
| FOV | |||||||||||||
| '@LX (m.@100m) | 7.8 | ||||||||||||
| '@HX (m.@100m) | 1.9 |
|
|
||||||||||
| Exit Pupil | |||||||||||||
| '@ LX (mm) | 10 | ||||||||||||
| '@HX (mm) | 2.5 | ||||||||||||
| Lens Coating Material | |||||||||||||
| Fully Coated | |||||||||||||
| Multi Coated | |||||||||||||
| Fully Multi Coated | [ √ ] | Sunshade: | Optional | ||||||||||
| Fast Focusing System: | YES | Mounts: | Optional | ||||||||||
