| CHENGDU MEIKE OPTICS CO., LTD | ||||||||||||
| Riflescope Specifications |
|
|||||||||||
| 6-24x44SF | ||||||||||||
| Specification | ||||||||||||
| Power | 6X~24X | Illuminated reticle | Special Notes: | |||||||||
| Objective (mm) | 44 | Illuminated color | 1. Erector Tube must be secured with metal screws. | Yes | ||||||||
| Focal Plane | second | Battery | 2. Erector Tube must have metal-to-metal contact. | Yes | ||||||||
| Tube Diameter(mm) | 30 | Parallax Focus: | YES | 3. Low Temp Epoxy may be used with Erector Tube. | Yes | |||||||
| Tube Material | 6061-T6 | Light Transmission Percentage (%) | 89% | 4. Fogproof with Dry Nitrogen | Yes | |||||||
| Finish (Anodized?) | Anodized | Recoil: "g's" & # of times | 1000G/100times | 5. Recoil: 1000 Rounds | Yes | |||||||
| Tube/Body Color(s) | W/E Clicks | 0.1MIL | ||||||||||
| Black | [ √ ] | Clicks per Turn | 60 |
|
||||||||
| Silver | Weight (oz/g) | 606g | ||||||||||
| Reticle Type | Metal Reticle | Waterproof: | YES | |||||||||
| Eye Relief | Fogproof: | YES | ||||||||||
| '@ LX (mm) | 93 | Shockproof: | YES | |||||||||
| '@HX (mm) | 80 | Elevation Adjustment Range (MOA) | 60 | |||||||||
| FOV | Windage Adjustment Range (MOA) | 60 | ||||||||||
| '@LX (ft.@100yds) | 17.2 | Parallax Setting | 10yds-infinity | |||||||||
| '@HX (ft.@100yds) | 4.3 | |||||||||||
| FOV | ||||||||||||
| '@LX (m.@100m) | 5.7 | |||||||||||
| '@HX (m.@100m) | 1.43 |
|
|
|||||||||
| Exit Pupil | ||||||||||||
| '@ LX (mm) | 7.3 | |||||||||||
| '@HX (mm) | 1.83 | |||||||||||
| Lens Coating Material | ||||||||||||
| Fully Coated | ||||||||||||
| Multi Coated | ||||||||||||
| Fully Multi Coated | [ √ ] | Sunshade: | Optional | |||||||||
| Fast Focusing System: | YES | Mounts: | Optional | |||||||||
