5-25X56FFP RIFLE SCOPE

Fit:

Major function:
Support to:
Feature
CHENGDU MEIKE OPTICS CO., LTD
Riflescope Specifications
5-25X56FFP
Specification
Power 5X~25X Illuminated reticle YES Special Notes:
Objective (mm) 56 Illuminated color RED 1. Erector Tube must be secured with metal screws. Yes
Focal Plane First Battery CR2032 2. Erector Tube must have metal-to-metal contact. Yes
Tube Diameter(mm) 34 Parallax Focus:       YES 3. Low Temp Epoxy may be used with Erector Tube. Yes
Tube Material 6061-T6 Light Transmission Percentage (%) 85% 4. Fogproof with Dry Nitrogen Yes
Finish (Anodized?) Anodized Recoil: "g's" & # of times 1000G/100times 5. Recoil: 1000 Rounds Yes
Tube/Body Color(s) W/E Clicks 0.173
     Black                                 [ √ ] Clicks per Turn 120
     Silver                                  Weight (oz/g) 1060g
Reticle Type                              Glass Etched Reticle Waterproof:       YES
Eye Relief Fogproof:          YES
         '@ LX (mm) 92 Shockproof:       YES
         '@HX (mm) 88 Elevation Adjustment Range (MOA) 100
FOV Windage Adjustment Range (MOA) 95
                   '@LX (ft.@100yds) 21 Parallax Setting  10M-∞
                   '@HX (ft.@100yds) 4.23
FOV
                   '@LX (m.@100m) 7
                   '@HX (m.@100m) 1.4
Exit Pupil
       '@ LX (mm) 11.2
       '@HX (mm) 2.24
Lens Coating Material
  Fully Coated
  Multi Coated
  Fully Multi Coated             [ √ ] Sunshade:    Optional
Fast Focusing System:    YES Mounts: Optional
